本設備為我公司最新開發的全伺服系統小型鋁塑包裝機。 本設備廣泛運用于只要行業藥片膠囊及醫療器械包裝,也可用于食品行業各種固體顆粒及液體包裝。
本設備為我公司最新開發的全伺服系統小型鋁塑包裝機。 本設備廣泛運用于只要行業藥片膠囊及醫療器械包裝,也可用于食品行業各種固體顆粒及液體包裝。
主要技術參數:
型號 |
100型 |
140型 |
沖裁次數(次/分) |
8-35次/分Times/min |
8-35次/分Times/min |
生產能力(版/時) |
2100版/時Blister/h(標準Standrd80×57mm) |
4200版/時Blister/h(標準Standrd80×57mm) |
最大成型面積及深度(毫米) |
標準250*110*10可定制到250*160*26(沖切頻率<25times/min) |
標準250*110*10可定制到250*160*26(沖切頻率<25times/min) |
標準行程范圍(毫米) |
105×60×20mm |
130×110×20mm |
標準版塊(毫米) |
80×57mm, 80×35mm, 95×65mm, 105×42mm, 105×55mm(可按用戶要求設計) |
|
壓縮空氣 |
0.15m3/min (自備)壓力:0.6-0.8Mpa |
0.15m3/min (自備)壓力:0.6-0.8Mpa |
電源總功率 |
380V/220V 50Hz 1.8kw |
380V/220V 50Hz 3.2kw |
主電機功率(千萬) |
0.55kw |
0.75kw |
PVC硬片(毫米) |
0.15-0.5×115mm |
0.15-0.5×140mm |
PTP鋁箔(毫米)PTP |
0.02-0.035×115mm |
0.02-0.035×140mm |
透析紙(毫米) |
50-100g/m2×115mm |
50-100g/m2×140mm |
模具冷卻 |
自來水或循環水60L/h |
|
外形尺寸(毫米) |
1600×500×1200mm |
2300×560×1410mm |
整機重量(千克) |
600kg |
1000kg |
Welcome to our website! Please send your words at any time in the following form and ask us, we will contact you and provide you with the corresponding service as soon as possible. Please write in English.
本設備為我公司最新開發的全伺服系統小型鋁塑包裝機。 本設備廣泛運用于只要行業藥片膠囊及醫療器械包裝,也可用于食品行業各種固體顆粒及液體包裝。
Learn MoreThis packaging machine was irinovatively developed by our own company. It is suitable for packaging chocolates, butter, biscuits, lollipop, can dy, cleani ng solution, perfume, esse nee, facemasks etc with AL/PL materials, not standard machin巳 can make special as per customer's requestintegrated with PVC forming, Automatic Feedi ng PTP sealing, batch nu mber p「in ting, perforation, cutti ng, waste win ding. It confomns to "GMP" requirement.
Learn MoreThis advanced high-tech XSJ Series Fish Food Blister Packaging Machine is innovated with success to meet the needs in the market by our own research, fellows. It's mainly suitable for packing red worms(akamushi), eelworm, artemia. baby shrimp etc. have been patented by the state patent administration. Its patent number is 200610008264.77. This machine has two models, model 250 and model 140. It is integrated mechanic, electric, pneumatic technologies. All the operations are controlled through signals sent off by the sensor switches. It's equipped with PLC program, simplifying the construction, making the blister locking synchronize with it to achieve the feeding the pet fish food. The packed food won't be destroyed in its cells and nutrients, and the products won't be deteriorated in the fridge at 18 below zero for within two years, which can keep the proteins and vitamins in the food from losing, keeping its sound performance of returning to water.
